SPARKLY 500SBW

SPARKLY 500SBW

470 watts Hybrid Spot Beam Wash Moving Head

SPARKLY 500SBW is a hybrid Spot, Beam, Wash moving head with a superior light output. It is powered by an Osram 470 watts lamp and fully loaded with functions and dynamic effects. It features a wide zoom angle starting at a narrow 2.5°, a CMY color mixing system with a CTO filter, static colors, 2 combinable prism wheels with 3 prism options each, static and rotating gobos and an animation wheel. This powerful multifunctional moving head is ideal for large scale stage and entertainment events.

SKU: Sparkly500SBW Category: Discontinued

Specifications
Downloads

SOURCE

Light source: Osram Sirius HRI 470 watts
Lamp life expectancy: 1,500 Hrs.

OPTICAL SYSTEM

Beam angle: 2.5° to 45°
Light output: 241,000 Lux @ 10m @ 2.5°
Electronic focus

DYNAMIC EFFECTS

Dimmer: 16 bit linear adjustment
Color mixing: CMY
Color wheel: 13 colors + White
CTO Filter
Static gobo: 14 gobos + open
Rotating gobo: 9 gobos + open
Gobo shake function
Prism 1: 8 facet prism – 6 linear facet prism – cylindrical
Prism 2: 8 facet prism – 6 linear facet prism – double layer
Prism are combinable with independant rotationFrost

CONTROL & PROGRAMMING

Control protocols: DMX/RDM
Display: 2.8’ touch screen display, can reverse 180°
Control channels: 34, 39 CHs

MOVEMENT

Pan: 540°
Tilt: 270°
Resolution: 16 bit

ELECTRICAL

Input voltage: 100-240V/50-60Hz
Power consumption: 600 watts

CONNECTIONS

DMX connections: 3 pin and 5 pin XLR In/Out male and female
Power connections: Powercon In

PHYSICAL

Dimensions: 410 x 250 x 690mm
Net weight: 24.5 Kg
Color: Black
IP rating: 20
