SOURCE
- Light Source: SMD5050 RGB LEDs
- LED Quantity:
- PIXISTRIP 60-O & PIXISTRIP 60-I: 60 LEDs per meter
- PIXISTRIP 32-O & PIXISTRIP 32-I: 32 LEDs per meter
OPTICAL SYSTEM
- Cover: Transparent diffuser
- View Angle: 120°
CONTROL & PROGRAMMING
- Pixels Control:
- PIXISTRIP 60-O & PIXISTRIP 60-I: 10 pixels per meter
- PIXISTRIP 32-O & PIXISTRIP 32-I: 16 pixels per meter
- Color Mixing: RGB
- Control Protocols: DMX, 44 FPS
- Control Channels:
- PIXISTRIP 60-O & PIXISTRIP 60-I: 30 channels per meter
- PIXISTRIP 32-O & PIXISTRIP 32-I: 48 channels per meter
- Address Setting: Manual
ELECTRICAL
- Input Voltage:
- PIXISTRIP 60-O & PIXISTRIP 60-I: 24V
- PIXISTRIP 32-O & PIXISTRIP 32-I: 12V
- Power Consumption:
- PIXISTRIP 60-O & PIXISTRIP 60-I: 12 watts per meter
- PIXISTRIP 32-O & PIXISTRIP 32-I: 10 watts per meter
CONNECTIONS
- Power and Data Connection: 15cm 5 pin female and male connection
- Cable Entry: Side
PHYSICAL
- Dimensions:
- PIXISTRIP 60-O & PIXISTRIP 60-I: 5000 x 17 x 5mm
- PIXISTRIP 32-O & PIXISTRIP 32-I: 5000 x 12 x 5mm
- Color: Black
- IP Rating:
- PIXISTRIP 60-O & PIXISTRIP 32-O: IP67
- PIXISTRIP 60-I & PIXISTRIP 32-I: IP20
- Operating Temperature: -20°C to 50°C
