SOURCE
- Light source: SMD3535 RGB LEDs
- LED quantity: 48 LEDs
OPTICAL SYSTEM
- Cover: Square opal diffuser
- View angle: 165°
CONTROL & PROGRAMMING
- Pixels control: 16
- Color mixing: RGB
- Control protocols: RDM, DMX
- Control channels: 48 CHs
- Address setting: RDM, Manual
ELECTRICAL
- Input voltage: 24V
- Power consumption: 10 watts / per meter
CONNECTIONS
- Power and data connection: 15cm 5 pin male/female cable
- Cable entry: Bottom
PHYSICAL
- Dimensions: 1000 x 28 x 46 mm (without bracket)
- Color: Silver
- Material: Aluminum 6063 with UV Protection
- Operating temperature: -30°C/50°C
- Humidity: 0-90%
- IP rating: 66
