SOURCE
- Light source: 40 watts RGBW COB LED
- LED life expectancy: 50,000 Hrs
OPTICAL SYSTEM
- Manual zoom
- Zoom range: 25° to 80°
- Light output: 5,000 Lux @ 2m @ 25°
PHOTOMETRICS
- CRI (Color Rendering Index) : >95; R9>90
- CQS (Color Quality Scale): >96
- TM-30 Rf (IES TM-30-15 Fidelity Index): >92
- TM-30 Rg (IES TM-30-15 Gamut Index): >98
- TLCI (Television Lighting Consistency Index): >98
KEY FEATURES
- 5 Dimmer curves
- Strobe
- Video flicker-free
- PMMA polymethyl methacrylate lens
- Barn doors included
CONTROL & PROGRAMMING
- Control protocols: Rotary, DMX, RDM
- Control Channels: ARC.1(3CH), AR1.D(4CH), ARC.2(4CH), AR2.D(5CH), AR2.S(6CH), HSV(3CH), STAG(11CH)
ELECTRICAL
- Input voltage: AC100-240V/50-60Hz
CONNECTIONS
- DMX Connections: 3 pin XLR In/Out male and female
- Power connections: PowerCon In
PHYSICAL
- Dimensions: 230 x 156 x 279mm
- Net weight: 2.2 Kg
- Color: Black
- Housing: Aluminum
- IP rating: 20
- Operating temperature: -5°C/45°C
